Pegasus Network

Outdoor and large indoor private 5G network, up to 100 MHz, for scalable industrial wireless connectivity.

Home > Pegasus 5G

Deploy your private 5G network

Pegasus Network is perfect for bringing reliable and secure wireless connectivity for smart manufacturing, university campuses, logistics applications such as picking and automatic warehouses, both indoor and outdoor.

Set up your own 5G network across your warehouses, factories, offices or campus

Connect hundreds of devices: smartphones, tablets, robots, AGVs, industrial routers, cameras, smart tools and barcode readers

Provision SIM and e-SIM cards, and allocate QoS priorities to each type of stream so traffic stays smooth across all your applications

Monitor bit rate, resource use and connected devices for every radio, from an interface built for IT administrators

Rely on our local partners to help you install and manage the network day to day

Complete and affordable

Pegasus Network is a turnkey solution, ready to deploy. Firecell builds, tests and maintains the whole 5G software, including the 5G Core, Radio Access Network and Network Management System, and pre-integrates it with industry-grade hardware optimised for connectivity.

It is a single solution for any deployment: All-in-One, vRAN or Pico architecture, installed and integrated on your premises by a System Integrator after radio planning of the area to be covered.

Pegasus Network

Pegasus Network is composed of the Firecell 5G Core and Network Management System running on a single server, RAN software, and multiple radio units and antennas, combined according to the architecture your site requires.

Bands

Max Bandwidth

SISO / MIMO

Max downlink bit rate

Max uplink bit rate

Synchronization

Output Power

Countries

Coverage

Pegasus High Power 20 W

n38

40 MHz

2x2 MIMO

320 Mbps

32 Mbps

N/A

2x20W

Germany, Sweden, Netherlands

1000 - 5000 m

Pegasus Mid Power 100 MHz

n48, n77, n78, n79

100 MHz

SISO, 2x2 MIMO, 4x4 MIMO

1350 Mbps

140 Mbps

GPS

4x5W

Brazil, Netherlands, Croatia, Sweden, Switzerland, Australia, France, UK, Poland, Belgium, Spain, Norway, Canada, Japan, South Korea, Taiwan (n79)

300 - 1000 m

Pegasus Mid Power 40 MHz

n38

40 MHz

SISO, 2x2 MIMO

320 Mbps

32 Mbps

GPS

4x5W

France

300 - 1000 m

Pegasus Low Power

n48, n77, n78, n79

100 MHz

SISO, 2x2 MIMO, 4x4 MIMO

1350 Mbps

140 Mbps

GPS

4x250 mW

Croatia, Switzerland, Poland, USA, Brazil, Netherlands, Sweden, Australia, France, UK, Belgium, Spain, Norway, Germany, Canada, Japan, South Korea, Taiwan (n79)

30 - 100 m
